Product No: P57-3999

Altrad Belle Hydraulic Breaker

Product No: P57-3999

Altrad Belle Hydraulic Breaker

Sturdy and reliable breaker featuring ultra dampened handles and designed for working together with the Altrad Belle Hydraulic Power Pack.

Features

Improved, lock-on, ergonomic handgrips.
Compatible with the range of ALTRAD Belle Hydraulic Power Packs.
Frequency and Blow Rates to achieve maximum productivity.
For use on a number of materials, from light brickwork to asphalt.
Delivered with 1/2” tail-hoses with 1/2” at-face couplings.
Hoses are removable for easy transportation and storage.
Can also be changed quickly if damaged.
Very reliable and simple to maintain = less servicing costs.

Available in the following models.

Specifications

Model BHB 23
Max Pressure (bar) 160
Hydraulic Flowrate (l/min) 20
Blows per Minute 1600
3-Axis Vibration (m/sec2) **11.97
Breaking Force (J) 65
Steel Size (mm) 25 x 108
Weight (kg) 23.5
Sound Power Level (dB LWA) 107

---------------

Model BHB25XS
Max Pressure (bar) 160
Hydraulic Flowrate (l/min) 20
Blows per Minute 1600
3-Axis Vibration (m/sec2 ) **6.5
Breaking Force (J) 55
Steel Size (mm) 32 x 160
Weight (kg) 25
Sound Power Level (dB LWA) 108

------------------------

Model BHB 27
Max Pressure (bar) 160
Hydraulic Flowrate (l/min) *20/30
Blows per Minute 1300 (20ltr)
Blows per Minute 2150 (30ltr)
3-Axis Vibration (m/sec2) **11.8 (20ltr)
3-Axis Vibration (m/sec2) **18.6 (30ltr)
Breaking Force (J) 85
Steel Size Hex (mm) 32 x 160
Weight (kg) 27
Sound Power Level (dB LWA) 108

These products may incur an additional carriage charge. Please contact sales for details.

Quick Links

£1176.50 ex VAT
£1411.80 inc VAT

Product Wishlist & Compare Placeholder

Free Standard Delivery over £100

Delivery cost calculated at checkout.



Quick Links




Sturdy and reliable breaker featuring ultra dampened handles and designed for working together with the Altrad Belle Hydraulic Power Pack.

Features

Improved, lock-on, ergonomic handgrips.
Compatible with the range of ALTRAD Belle Hydraulic Power Packs.
Frequency and Blow Rates to achieve maximum productivity.
For use on a number of materials, from light brickwork to asphalt.
Delivered with 1/2” tail-hoses with 1/2” at-face couplings.
Hoses are removable for easy transportation and storage.
Can also be changed quickly if damaged.
Very reliable and simple to maintain = less servicing costs.

Available in the following models.

Specifications

Model BHB 23
Max Pressure (bar) 160
Hydraulic Flowrate (l/min) 20
Blows per Minute 1600
3-Axis Vibration (m/sec2) **11.97
Breaking Force (J) 65
Steel Size (mm) 25 x 108
Weight (kg) 23.5
Sound Power Level (dB LWA) 107

---------------

Model BHB25XS
Max Pressure (bar) 160
Hydraulic Flowrate (l/min) 20
Blows per Minute 1600
3-Axis Vibration (m/sec2 ) **6.5
Breaking Force (J) 55
Steel Size (mm) 32 x 160
Weight (kg) 25
Sound Power Level (dB LWA) 108

------------------------

Model BHB 27
Max Pressure (bar) 160
Hydraulic Flowrate (l/min) *20/30
Blows per Minute 1300 (20ltr)
Blows per Minute 2150 (30ltr)
3-Axis Vibration (m/sec2) **11.8 (20ltr)
3-Axis Vibration (m/sec2) **18.6 (30ltr)
Breaking Force (J) 85
Steel Size Hex (mm) 32 x 160
Weight (kg) 27
Sound Power Level (dB LWA) 108

These products may incur an additional carriage charge. Please contact sales for details.

Mills Part Numbers

P57-3840 Altrad Belle BHB23 Medium / Heavy Weight Hydraulic Breaker

P57-3999 Altrad Belle BHB25XS Low Vibration Hydraulic Breaker

P57-3841 Altrad Belle BHB27 Heavy Weight Hydraulic Breaker

To see our delivery charges, please click here

To see our terms regarding returns, please click here

Download Datasheet
Download Bhb Breaker Operator S Manual
Download Bhb Breaker Range Datasheet
