Product No: C72-2503

Megger DCM310 Digital Clamp Meter

Product No: C72-2503

Megger DCM310 Digital Clamp Meter

The DCM310 is an ideal clamp meter for use during the installation, maintenance and checking of electrical systems and equipment.

It will measure AC current (50 - 60 Hz) up to 400 A, with a Data-hold feature to freeze the displayed value for use in confined situations where the display may be difficult to read. The DCM310 also has a max-hold
feature to automatically store and display the maximum value measured over a period of time.

It is safety rated to IEC 61010 CAT III 600 V offering high levels of protection to the operator.

A carrying case is included, and even without the case, the instrument is rated to withstand a 1.2 m drop onto a hard surface without damage.

The compact clamp jaw enables cables to be measured as large as 27 mm diameter, covering the majority of applications within the electrical system installation industry.

Ideal for use by anyone working on basic electrical systems or equipment, these instruments are also suitable for the majority of applications encountered by the electrical contractor.

Please see datasheet for full specifications

Quick Links

£112.78 ex VAT
£135.34 inc VAT

Product Wishlist & Compare Placeholder

Free Standard Delivery over £100

Delivery cost calculated at checkout.



Quick Links




The DCM310 is an ideal clamp meter for use during the installation, maintenance and checking of electrical systems and equipment.

It will measure AC current (50 - 60 Hz) up to 400 A, with a Data-hold feature to freeze the displayed value for use in confined situations where the display may be difficult to read. The DCM310 also has a max-hold
feature to automatically store and display the maximum value measured over a period of time.

It is safety rated to IEC 61010 CAT III 600 V offering high levels of protection to the operator.

A carrying case is included, and even without the case, the instrument is rated to withstand a 1.2 m drop onto a hard surface without damage.

The compact clamp jaw enables cables to be measured as large as 27 mm diameter, covering the majority of applications within the electrical system installation industry.

Ideal for use by anyone working on basic electrical systems or equipment, these instruments are also suitable for the majority of applications encountered by the electrical contractor.

Please see datasheet for full specifications

To see our delivery charges, please click here

To see our terms regarding returns, please click here

Download Datasheet
Download C72 2503 Dcm310 Datasheet
