Product No: S83-3661

Tempo ADSL Load Attenuator

Product No: S83-3661

Tempo ADSL Load Attenuator

Tempo ADSL Load Attenuator available in 20dB and 40dB models.

Quick Links

Type

£13.17 ex VAT

£15.80 inc VAT

Product Wishlist & Compare Placeholder

Free Standard Delivery over £100

Delivery cost calculated at checkout.

Quick Links

Full description

The nominal 500 kBit/s ADSL service can be supplied over circuits with up to 60dB loss at 300kHz. When deploying ADSL service it is useful to know if the circuit looking back from the test point meets this requirement.

By placing a device that provides a known attenuation at 300kHz between the test equipment and the test point the capability of the circuit can be verified.

Two such devices are currently available that provide a nominal 20dB and 40dB attenuation at 300kHz.

By connecting the two in series a nominal 60dB attenuation is realised.

Available in 20dB and 40dB models

BT Openreach References

20dB - Ref 023858

40dB - Ref 023857

Mills Part Numbers

S83-3661 Tempo ADSL Attenuator 20dB

S83-3662 Tempo ADSL Attenuator 40dB
