Product No: T-72M12-FULL KIT

Sumitomo T-72M12+ Ribbon Splicer Kit With Fibre Holders, Thermal Stripper & Cleaver

Product No: T-72M12-FULL KIT

Sumitomo T-72M12+ Ribbon Splicer Kit With Fibre Holders, Thermal Stripper & Cleaver

The Sumitomo T-72M12+ has the industry's only dual independent heaters and Auto Clamping Adjustment System "ACAS"

Compact, Lightweight & Faster

2.1kg with battery for 180 splice & heat cycles

Faster 11s splice in SM Quick Mode

Reduced 35s heat shrink time

Dual ovens with flexible clamps

Independent Fast-heating 35s

Productive

Programmable

User selectable clamp operation

Auto Clamping Adjustment System “Active-ACAS”

Patented key technology for excellent loss perforemance

Clamp pressure can be automatically optimized and fibre offset is corrected

High Environmental Durability

IPx2 water resistance

IP5x dust resistance

Splice at 50°C

Work at 3660m

76cm drop on 5 faces

Brand-new touch panel and UI

Wide and high resolution touch panel -5" touch screen colour LCD display

Smartphone-like easy operation

Wireless LAN connectivity to SumiCloud™

SumiCloud™ smartphone App. to support splicing job

WLSD card brings SumiCloud™ services to your splicer via our smartphone App.

Kit comprises:

1x T-72M12+ Fusion Splicer
1x BU-16
1x PC-AC3 Power Cord
1x ADC-16 Power Supply module
1x T-39_SCT Cooling Tray
1x Hand Strap
1x Pair of ER-10 Spare Electrodes
1x Quick Reference Guide
1x CC-72 Carrying Case (MKII)
1x Shoulder strap for CC-71
1x USB cable (L=1.0M)
1x Important safety precautions
1x WLSD-0416 card
1 x Lead/AC/IEC_C13-UK/3_Amp/PC-AC
1 x Fibre Holders/FHS-025/Moulded
1 x Fibre Holders/FHS-09/Moulded
1 x Fibre holders/FHM-12V - For use with standard encapsulated ribbons and pliable ribbons
1 x Cleaver/FC-6RM-C
1 x Jacket Remover/Heated/JR-6+/Kit
1 x Lead/DC Vehicle Power/PC-V16/T-57 & T-72
1 x Lead/AC/IEC_C7-UK/3_Amp
1 x Fibre Arrangement Tool/OFA-01/Semi-hardcase
1 x Brush/V-Groove Cleaning/VGT-2

Quick Links

£7587.23 ex VAT
£9104.68 inc VAT

Product Wishlist & Compare Placeholder

Free Standard Delivery over £100

Delivery cost calculated at checkout.



Quick Links




The Sumitomo T-72M12+ has the industry's only dual independent heaters and Auto Clamping Adjustment System "ACAS"

Compact, Lightweight & Faster

2.1kg with battery for 180 splice & heat cycles

Faster 11s splice in SM Quick Mode

Reduced 35s heat shrink time

Dual ovens with flexible clamps

Independent Fast-heating 35s

Productive

Programmable

User selectable clamp operation

Auto Clamping Adjustment System “Active-ACAS”

Patented key technology for excellent loss perforemance

Clamp pressure can be automatically optimized and fibre offset is corrected

High Environmental Durability

IPx2 water resistance

IP5x dust resistance

Splice at 50°C

Work at 3660m

76cm drop on 5 faces

Brand-new touch panel and UI

Wide and high resolution touch panel -5" touch screen colour LCD display

Smartphone-like easy operation

Wireless LAN connectivity to SumiCloud™

SumiCloud™ smartphone App. to support splicing job

WLSD card brings SumiCloud™ services to your splicer via our smartphone App.

Kit comprises:

1x T-72M12+ Fusion Splicer
1x BU-16
1x PC-AC3 Power Cord
1x ADC-16 Power Supply module
1x T-39_SCT Cooling Tray
1x Hand Strap
1x Pair of ER-10 Spare Electrodes
1x Quick Reference Guide
1x CC-72 Carrying Case (MKII)
1x Shoulder strap for CC-71
1x USB cable (L=1.0M)
1x Important safety precautions
1x WLSD-0416 card
1 x Lead/AC/IEC_C13-UK/3_Amp/PC-AC
1 x Fibre Holders/FHS-025/Moulded
1 x Fibre Holders/FHS-09/Moulded
1 x Fibre holders/FHM-12V - For use with standard encapsulated ribbons and pliable ribbons
1 x Cleaver/FC-6RM-C
1 x Jacket Remover/Heated/JR-6+/Kit
1 x Lead/DC Vehicle Power/PC-V16/T-57 & T-72
1 x Lead/AC/IEC_C7-UK/3_Amp
1 x Fibre Arrangement Tool/OFA-01/Semi-hardcase
1 x Brush/V-Groove Cleaning/VGT-2

To see our delivery charges, please click here

To see our terms regarding returns, please click here

Download Datasheet
Download 072M12 Emea 2023.10.02 1
