Prysmian Casalink CTB External Customer Termination Box MK1

Product No: XCPSC03744

Prysmian Casalink CTB External Customer Termination Box MK1

The CTB External Customer Termination Box is a wall mounted product can be used for splicing the CBT drop cable
to the Internal External cable that enters the house.

The box also has the added feature of a built in figure of eight routing system, that prevents fibre movement when aerial input cables are subjected to ice and wind loading.

The unit is supplied with a gas/water block for the input cable and is supplied in dark grey with a sealing rating
of IP55.

Customer drop cables of 3 to 6mm can be distributed from the box.

Features and Benefits

• Supplied in dark grey.
• All fibres are positively managed to maintain a 30mm minimum bend radius within the wall box.
• A unique figure of eight locking system is integrated into the box to prevent the movement of fibres from aerial input cables when subjected to ice and wind loading.
• Sealed to IP55.
• UV stable to prevent discolouration of the material and manufactured from UL94-V0 rated materials.

Contents

4 x SE Splice trays
1 x Wall fixing Kit
2 x Drop Sealing Grommet.
3 x Cable Ties
1 x M20 Entry Cable Gland 4-9mm
1 x Aerial Cable Locking Kit

Technical Data

• Number of cable ports: 1 input, 6 output
• Maximum cable diameter (mm): 9 Input, 3-6 Output
• Maximum number of splice trays: 4
• Required space envelope (mm): (w) 220 x (h) 150 x (d) 50.
• Operating temperature: -20 degrees C to + 50 degrees C (5 to 95% RH)

Material

• Box: FR ABS Dark Grey (RAL7030)
• Splice trays: FR ABS White (RAL9016)

Testing

• Sealing: IP55
• Optical: Tested 1310nm,1550nm and 1625nm
• Dry heat: BS EN 60068-2-2 Test Bb
• Damp heat: IEC 60068-2-3: 1969
• Change of temperature: IEC 60068-2-14: 1984
• Vibration: IEC 60068-2-6: 1995
• Shock: IEC 60068-2-27: 1987

Packing Dimensions (mm): (w) 230 x (h) 160 x (d) 60
Packed Weight (Kg): 0.55
Net Weight (Kg): 0.5
