Product No: E00-0480

Ripley Miller MB11 Heavy Duty Shaving Tool 6-26mm

Product No: E00-0480

Ripley Miller MB11 Heavy Duty Shaving Tool 6-26mm

Ideal for Corning’s armoured & non-armoured RocketRibbon® cable, this ergonomic tool is designed for shaving access windows on thick jacketed cables.

Features:

  • Ergonomic handle for reduced fatigue and easier force generation
  • L-Bracket to apply clamping force on cable, ensuring a reliable cut
  • Use wing-knob to adjust cable setting
  • Tool body accurately aligns blade for optimum shaving angle
  • Tool-free blade replacement with captive hardware
  • Offset block allows blade to be reversed for double blade life
  • Compatible with standard utility knife blades
  • Reinforced polymer body with metal inserts for toughness and wear resistance

Compatibility

Corning RocketRibbon 12F - 864F 0.33” - 0.87” (8.38 mm – 22.1 mm)
OFS AccuRoll Dry Core Armoured (Metallic) 12F - 864F 0.39” - 0.81” (10 mm – 20.6 mm)
Thick walled tube, thin walled microduct 0.25” – 1.02” (6 mm – 26 mm)
Other armoured cables w/ steel strength members 0.25” – 1.02” (6 mm – 26 mm)

Dimensions 9" x 3" x 2.75" (228.6 x 76.2 x 69.85 mm)

Weight 10.9 oz (310 g)

Quick Links

£96.72 ex VAT
£116.06 inc VAT

Product Wishlist & Compare Placeholder

Free Standard Delivery over £100

Delivery cost calculated at checkout.



Quick Links




Ideal for Corning’s armoured & non-armoured RocketRibbon® cable, this ergonomic tool is designed for shaving access windows on thick jacketed cables.

Features

Ergonomic handle for reduced fatigue and easier force generation
L-Bracket to apply clamping force on cable, ensuring a reliable cut
Use wing-knob to adjust cable setting
Tool body accurately aligns blade for optimum shaving angle
Tool-free blade replacement with captive hardware
Offset block allows blade to be reversed for double blade life
Compatible with standard utility knife blades
Reinforced polymer body with metal inserts for toughness and wear resistance

Compatibility

Corning RocketRibbon 12F - 864F 0.33” - 0.87” (8.38 mm – 22.1 mm)
OFS AccuRoll Dry Core Armoured (Metallic) 12F - 864F 0.39” - 0.81” (10 mm – 20.6 mm)
Thick walled tube, thin walled microduct 0.25” – 1.02” (6 mm – 26 mm)
Other armoured cables w/ steel strength members 0.25” – 1.02” (6 mm – 26 mm)

Dimensions 9" x 3" x 2.75" (228.6 x 76.2 x 69.85 mm)

Weight 10.9 oz (310 g)

To see our delivery charges, please click here

To see our terms regarding returns, please click here

Download Datasheet
